1m-6m PP Biaxial Geogrid Designed For Road Construction Project

Name: 1m6m PP Biaxial Geogrid Designed For Road Construction Project
Brand: Shuntian
Price: 1.3 USD

Quality 1m-6m PP Biaxial Geogrid Designed For Road Construction Project for sale

Brand Name : Shuntian

Model Number : ST01

Certification : ISO9001

Place of Origin : China

MOQ : 1000m2

Price : 1.3-2.5$

Payment Terms : T/T

Supply Ability : 100000000m2

Delivery Time : 20Days

Packaging Details : Any requirement

Product Name : Geogrid

Keywords : PP Biaxial Geogrid

Mesh size : 12.7*12.7mm. 25.4*25.4mm,35mm*35mm,

Width : 1m--6m,Special Requests

Length : 50-100m/roll

Structuretype : Biaxial,

Material : PP

Elongationatbreak : 5-15%

Contact Now

PP Biaxial Geogrid Designed For Road Construction Project

Plastic Geogrid

Geogrid is a high-strength polymer geosynthetic material, widely used in civil engineering projects. It features excellent tensile strength, corrosion resistance, and long-term durability, which can effectively reinforce soil, distribute loads, prevent soil erosion, and improve the stability of engineering structures. Suitable for road construction, slope protection, retaining walls, and landfill projects, geogrid plays a key role in reducing project costs and extending the service life of projects.

Fiberglass Geogrid Form

Item	Specification	Description
Material	PP (Polypropylene), PE (Polyethylene), PET (Polyester)	Food-grade raw materials, non-toxic and environmentally friendly
Type	Uniaxial Geogrid, Biaxial Geogrid	Uniaxial for one-way reinforcement; Biaxial for two-way reinforcement
Tensile Strength	Uniaxial: 20-150 kN/m; Biaxial: 10-80 kN/m	Tested according to GB/T 17689-2014 standard
Elongation at Break	≤10% (at maximum tensile strength)	Low creep, stable performance under long-term load
Mesh Size	20×20mm, 30×30mm, 40×40mm, 50×50mm	Customizable according to project requirements
Thickness	1.5-5.0mm	Depends on material and strength grade
Width & Length	Width: 2-6m; Length: 50-100m/roll	Customizable roll size for easy transportation and construction
Service Life	≥50 years (under normal working conditions)	UV-resistant, corrosion-resistant to acid, alkali and salt

Performance Indicators

150g or 200g of geotextiles and 30 or 40 kN/m PP biaxial geogrid composite. Another: specific models of geogrid and geotextile can be customized as required. Geogrid with a width of 3.95m and 5.95m.
